| Using permanent magnet motors drive, Reduced transmission energy consumption. |
| By using permanent magnet motors, the traditional belt pulley transmission design has been eliminated, reducing kinetic energy loss and saving about 10% energy |
| compared to the traditional asynchronous motor. According to the demand, 380V and 690V high-voltage standard motors can be customized, with lower energy |
| consumption and maintenance costs under the same output power. |
| Electrical separation of strengths and weaknesses, high system stability. |
| Adopting strong and weak current separation to reduce interference of high voltage on weak current system and reduce safety risk. Responsible for different function |
| modules, accurately predicting location of faults in case of system malfunction, facilitating quick countermeasures, shortening downtime and maintenance time. |
| |
| |
| Applications |
|
|
|
| Digital inkjet, Printing ink, Lithium battery materials, Ceramic materials, Conductive materials, Nano new materials, MLCC, Alumina, Coating, Paint, Buffing and Polishing |
| Materials, LCD and Other nano materials etc. |
| |
| |
| Technical Parameter |
| |
| |
| Model |
Chamber |
Fineness |
Rotor Speed |
Bead Rate |
Power |
Bead Dia. |
Batch Capacity |
|
| MDM-30 |
30L |
100nm - 2um |
1200 - 2500rpm |
70 - 85% |
35kw |
0.2 - 2.0mm |
100 - 1000L |
|
| MDM-60 |
60L |
100nm - 2um |
1070 - 1500rpm |
70 - 85% |
55kw |
0.2 - 2.0mm |
200 - 2000L |
|
| MDM-100 |
100L |
100nm - 2um |
1070 - 1500rpm |
70 - 85% |
116kw |
0.2 - 2.0mm |
500 - 4000L |
|
| MDM-150 |
150L |
100nm - 2um |
900 - 1650rpm |
70 - 85% |
130kw |
0.2 - 2.0mm |
800 - 6000L |
|
| MDM-300 |
300L |
100nm - 2um |
900 - 1650rpm |
70 - 85% |
225kw |
0.2 - 2.0mm |
2000 - 10000L |
|
| MDM-400 |
400L |
100nm - 2um |
900 - 1650rpm |
70 - 85% |
320kw |
0.2 - 2.0mm |
3000 - 12000L |
|
| MDM-500 |
500L |
100nm - 2um |
900 - 1650rpm |
70 - 85% |
370kw |
0.2 - 2.0mm |
4000 - 18000L |
|
| MDM-700 |
700L |
100nm - 2um |
900 - 1650rpm |
70 - 85% |
460kw |
0.2 - 2.0mm |
5000 - 30000L |
|
| MDM-1000 |
1000L |
100nm - 2um |
550 - 1300rpm |
70 - 85% |
580kw |
0.2 - 2.0mm |
8000 - 40000L |
|
| |
| |
