Metal Powder Pulverizer





Technical Parameter

Model
Rotor Dia.
Rev.
Fineness
Power
Capacity
AVR450
450mm
3000rpm
10 - 300um
30kw
40 - 1200kg/hour
AVR600
600mm
2000rpm
10 - 300um
45kw
50 - 1500kg/hour
AVR1000
1000mm
2000rpm
10 - 300um
75kw
800 - 3000kg/hour
AVR1250
1250mm
1600rpm
10 - 300um
110kw
1200 - 5000kg/hour


Application
Platinum Particles
Copper Particles
Chromium Particles
Gold Particles


Performance Advantages
AVR series is a vertical axis reflective pulverizer that can simultaneously complete two processing
steps: Powder puverizing and Powder sorting.
Equipped with an airflow control valve and a graded impeller stepless speed regulator, the fineness
of the product can be controlled without stopping the machine.
The machine has air cooling function, which reduces temperature rise during pulverizing, the product
has uniform particle size and narrow distribution surface.
